UsmanAliNET
Shop G30/G40 Ground Floor Al-Lateef Centre Kacha Hall Road Lahore.
The Cisco WS-C4500X-16SFP+ is a specific model within the Catalyst 4500-X series, featuring 16 SFP/SFP+ ports designed for enterprise aggregation with front-to-back airflow. It is a fixed-configuration, rack-mountable (1RU) switch that provides high scalability and integrated services.
Key Specifications
Feature
Specification
Source
Ports 16 x SFP/SFP+ (supports both 1G and 10G transceivers)
Expansion Slot 1 optional uplink module slot (supports an additional 8 SFP/SFP+ ports with the C4KX-NM-8SFP+ module)
Switching Capacity Up to 800 Gbps (scaling to 1.6 Tbps with VSS)
Forwarding Rate Up to 250 Mpps (IPv4)
Airflow Front-to-back cooling (indicated by burgundy handles)
Power Supplies Supports dual, hot-swappable power supplies (must be ordered separately)
Software Runs Cisco IOS XE Software (IP Base feature set included)
High Availability Supports Virtual Switching System (VSS) and redundant fans/power supplies
The Cisco 4500-X switch has a nominal power consumption of 330W and a maximum of 400W, with a maximum power supply capacity of 750W (for both AC and DC options). The total BTU/hr is approximately 1122 BTU/hr for nominal and 1365 BTU/hr for the maximum rating.
One Month Warranty Single Power Supply
