Processors: Dual Intel Xeon E5‑2600 v3/v4 (supports up to 18 cores/CPU)
Memory: 24 DDR4 DIMM slots (ECC RDIMM/LRDIMM), up to 768 GB at 2133 MT/s; note potential firmware expansion to 1.5 TB
495 W AC (Platinum): 100–240 V autoranging, max heat 1908 BTU/hr
750 W AC (Titanium or Platinum): 100–240 V autoranging, Titanium max heat 2843 BTU/hr
1100 W AC (Platinum): 100–240 V autoranging, max heat 4100 BTU/hr
(Optional 1100 W DC, 48–60 V DC)
Internal: 8 × 3.5″ LFF hot-swappable HDD/SSDs (S...
Processors: Dual Intel Xeon E5‑2600 v3/v4 (supports up to 18 cores/CPU)
Memory: 24 DDR4 DIMM slots (ECC RDIMM/LRDIMM), up to 768 GB at 2133 MT/s; note potential firmware expansion to 1.5 TB
495 W AC (Platinum): 100–240 V autoranging, max heat 1908 BTU/hr
750 W AC (Titanium or Platinum): 100–240 V autoranging, Titanium max heat 2843 BTU/hr
1100 W AC (Platinum): 100–240 V autoranging, max heat 4100 BTU/hr
(Optional 1100 W DC, 48–60 V DC)
Internal: 8 × 3.5″ LFF hot-swappable HDD/SSDs (SATA, SAS, near-line SAS)
External: Compatible with iSCSI/FC SANs; internal optical drive or PowerVault RD1000 tape on 2.5″ chassis
PCIe Slots: Up to 7 × PCIe 3.0 slots (mix of x8/x16 full/half-height)
Embedded NICs: 4 × 1 GbE LOM standard, optional 10 GbE/40 GbE NDCs
theserverstore. com
Feature Specification
Drive Bays 8 × 3.5″ hot-plug SAS/SATA/NL-SAS/SSD
RAID Controller PERC H730, 12 Gb/s SAS, 1 GB cache, RAID 0/1/5/6/50/60
CPUs 2 × Intel Xeon E5‑2600 v3/v4 (up to 18 cores each)
Memory 24 × DDR4 ECC (RDIMM/LRDIMM), up to 768 GB (max. 2133 MT/s)
PCIe Expansion 7 × PCIe 3.0 (mix x8/x16)
Embedded NIC 4 × 1 GbE (LOM); optional 10/40 GbE
Management iDRAC8 with Lifecycle Controller; iDRAC8 Enterprise optional
Power (dual PSU) 495 W, 750 W (P/T), 1100 W (P), optional 1100 W DC
Redundancy Hot-plug drives, redundant PSUs, fans, ECC memory
Dimensions & Weight ~2U, 482 × 87 × 684 mm; ~29 kg
