Product: Solar Inverter Model: SMT-10K-TL-TH DC (PV) Input Maximum PV Power: 14,000 W Maximum PV Voltage: 1000 V DC Rated PV Voltage: 720 V DC MPPT Voltage Range: 200–880 V DC MPPT Trackers: 2 Max. PV Input Current: 12.5 A per MPPT Battery Side Battery Voltage Range: 180–800 V DC Rated Battery Voltage: 400 V DC Max. Charge/Discharge Current: 25 A AC Output (Grid) – 3-Phase System Rated AC Power: 10,000 W (10 kW) Rated AC Voltage: 230 V / 400 V AC (3/N/PE) 220 V / 380 V AC (3/N/PE) Rated Freq... Product: Solar Inverter Model: SMT-10K-TL-TH DC (PV) Input Maximum PV Power: 14,000 W Maximum PV Voltage: 1000 V DC Rated PV Voltage: 720 V DC MPPT Voltage Range: 200–880 V DC MPPT Trackers: 2 Max. PV Input Current: 12.5 A per MPPT Battery Side Battery Voltage Range: 180–800 V DC Rated Battery Voltage: 400 V DC Max. Charge/Discharge Current: 25 A AC Output (Grid) – 3-Phase System Rated AC Power: 10,000 W (10 kW) Rated AC Voltage: 230 V / 400 V AC (3/N/PE) 220 V / 380 V AC (3/N/PE) Rated Frequency: 50 Hz / 60 Hz Rated AC Current: 14.5 A Maximum AC Current: 16.7 A Power Factor: 0.8 (capacitive or inductive) THD (Total Harmonic Distortion): <3% AC Output (Load/EPS/Off-grid) Rated Power: 10,000 W Rated Voltage: 400 V / 380 V AC (3/N/PE) Rated Frequency: 50 Hz / 60 Hz Rated Current: 14.5 A Max. AC Current: 16.7 A Switching Time: 10 ms Peak Power at 25°C: 11 kW (30 min) 13 kW (5 min) 15 kW (5 sec) THD: <3% Efficiency MPPT Efficiency: 99.9% European Efficiency: 97% Maximum Efficiency: 97.6% Charge/Discharge Efficiency: 97.6% / 96% Protections & Safety DC Reverse Polarity Protection Anti-islanding Protection Residual Current Protection AC Short-Circuit Protection AC Overcurrent & Overvoltage Protection Integrated DC Switch Insulation Monitoring General Specifications Dimensions: 548 × 550 × 188 mm Weight: <40 kg Standby Consumption: <20 W Ingress Protection: IP65 (dust & water-resistant) Operating Temperature: –25 °C to +60 °C Altitude: <2000 m Noise Emission: <30 dB (quiet operation) Cooling: Natural cooling (no fans) Communication & Display Interfaces: WiFi, GPRS (optional), RS485 LED Display Note:imported from norway only inverter just like a brand new Show More
